98
Functions
FET amp adjustment
1 (Transmitter and amp connection)
Connect the transmitter and amp in accordance
with the connection diagram on the preceding
page.
2 (Amp setup)
Press the (+) and (-) buttons simultaneously for
at least 1 second.
- "NOW ACTIVE" appears on the screen, and a special signal for amp
adjustment is output from the transmitter OSC terminal. In this state, the
amp can be adjusted.
CAUTION!
NOW MOD OFF
* At setup, "NOW ACTIVE" blinks and
a signal is output in the setup mode.
Execute amp setup in accordance with the in-
struction manual supplied with the amp.
HRS MC setup/MC-SETUP
3 When ending adjustment, turn off the transmitter
power switch.
If the power switch is not turned off, this setup
amp mode cannot be reset. If returned to the ini-
tial screen in this setup mode, a blinking mes-
sage like that shown below will appear.
To Next Page
