G-Tek CR-2010 PRO Series User Manual

32
Configuration
6.2.7.1 Sensor
Three types of sensor inputs are being accepted by the chart recorder.
6.2.7.1.1 RTD
It is Resistance Temperature Sensor. The sensor name is PT100.
A platinum resistance temperature detector (RTD) is a device with a typical resistance of 100 Ω at 0°C.
It consists of a thin film of platinum on a plastic film. Its resistance varies with temperature and it can
typically measure temperatures up to 750 °C. The relationship between resistance and temperature
is relatively linear as shown below for a sample 100 Ω RTD.
Figure 26 - RTD Sensor
6.2.7.1.2 Thermocouple
Recorder accepts as listed under.
❖ TC-J
It is made up of iron (+ve electrode) & constantan (-ve electrode). It operates over the
temperature range of (-200) to (1200) C temperature. Its sensitivity is 50 uV/C.
❖ TC-K
It is made up of chromel (+ve electrode) & alumel (-ve electrode). It operates over the
temperature range of (-200) to (1372) C temperature. Its sensitivity is 41 uV/C.
❖ TC-C
It is made up of tungsten (+ve electrode) & rhenium (-ve electrode). It operates over the
temperature range of (0) to (2300) C temperature. Its sensitivity is 46 uV/C.
-
+
