Specification
SPECIFICATION
The Specifications of chart recorder are:
Table 5 Specification of Chart Recorder
Model No
CR2010 Pro; 11" recorder
Product Code*
3xxxx
Pens
No. of Pens
1/2
Pen Marking
Continuous
Pen Response Time
<5Sec (Full Scale)
Pen Resolution
Stepper Motor Controlled better than 0.1% FSD
Overshoot
None
Chart
Chart Speed
15min/rev to 255 hours/rev
Chart Calibrated Radius
4.1" (approx. 107mm)
Chart Ranges
Standard (Refer Table 2) / Customized Please
specify
Display, Operator Panels and Input
Display Type
Digital, 8 digits ultra-bright LED Numeric/semi
alphabetic
Display Height
0.3”
Status Indicator
Channel Number and corresponding parameter
values, prompts and messages displayed for
ease for setup and programming.
Panel Keys
Front panel KB consisting of 5 keys for
programming and calibration
Analog Input
RTD PT-100 / 0-5V/ 4-20 mA / 0-20 mA
(External shunt resistance)/TCJ-K-C-R-S-T-B-E-N
Sensor Type and Range
Refer to Table 1
Scan Rate
Continuous 1 reading per second
Protection
Input Impedance
RTD/VOLT/TC >20mΩ
