3.3 OPTIONAL FEATURES
Following features are available for this circular chart recorder.
• 11” Chart Width
• Digital, 8-digit ultra-bright LED Numeric / semi alphabetic Display
• Single & Dual Analog Input channel
• Direct Input standard PT-100 sensor
• Standard Input for popular Thermocouples like J/K/C/R/S/T/B/E/N
• Process Input through 4-20mA / 0-20mA / 0-5V
• Cost effective fixed sensor input or Field configurable sensor input
• 15 min/rev to 255 hour/rev chart speed
• Universal Power Supply 85-264V AC, 47-63Hz
• Other power supply inputs on request
• Battery Backup
• One Relay per channel (Optional).
It is possible that the chart recorder you received may or may not be fitted with the optional
features. Please refer to the product code to know about installed options in your chart recorder.
3.4 UNPACKING AND INSPECTION OF RECORDER
G-Tek recorders are dispatched in a recyclable, environment friendly package specially designed to
give adequate protection during transit. If the outer box shows sign of damage, it should be opened
immediately, and the recorder be examined. If there is evidence of damage, the instrument should
not be operated, and the local representative contacted for instructions. Ensure that all accessories
and documentation is removed from the box. Open the door of the recorder by rotating the knob
(figure A). Open the chart plate by opening the captive Screw (figure B) and inspect the recorder for
an immediate use, re-pack the recorder in its original packing. If the recorder is for immediate use,
you can start installing it now as per following instructions. Please preserve the original packing along
with all internal packing for future transport requirements.
