G-Tek CR-2010 PRO Series - Figure 15

To Next Page

To Previous Page

Configuration

Set point Low

The lower limit of value, after which relay will be toggled

Chart Zero

Minimum value of the output which is considered as a zero scale on chart

Chart Span

Chart span is defined as the difference between Chart Full Scale and Chart

Zero

Communication Parameters:

Device Address

Address of chart recorder for communication with computer

Saving Configuration

Channel parameters

The chart recorder can be Configured using front panel Keyboard. User can enter the configuration.

The following figure shows the main menu sequence:

Chnl 1

Chnl 2

Pen Park

Chng Pen

Chrt Spd

Display

Chnl Scn

CJC

1 128.55

Display

parameter

Figure 15 - Main menu display
