Conditional Jumps
The DMC-40x0 provides Conditional Jump (JP) and Conditional Jump to Subroutine (JS) instructions for branching
to a new program location based on a specified condition. The conditional jump determines if a condition is
satisfied and then branches to a new location or subroutine. Unlike event triggers, the conditional jump instruction
does not halt the program sequence. Conditional jumps are useful for testing events in real-time. They allow the
controller to make decisions without a host computer. For example, the DMC-40x0 can decide between two
motion profiles based on the state of an input line.
Command Format - JP and JS
FORMAT DESCRIPTION
JS destination, logical condition Jump to subroutine if logical condition is satisfied
JP destination, logical condition Jump to location if logical condition is satisfied
The destination is a program line number or label where the program sequencer will jump if the specified condition
is satisfied. Note that the line number of the first line of program memory is 0. The comma designates “IF”. The
logical condition tests two operands with logical operators.
Logical operators:
OPERATOR DESCRIPTION
<
less than
>
greater than
=
equal to
<=
less than or equal to
>=
greater than or equal to
<>
not equal
Conditional Statements
The conditional statement is satisfied if it evaluates to any value other than zero. The conditional statement can be
any valid DMC-40x0 numeric operand, including variables, array elements, numeric values, functions, keywords,
and arithmetic expressions. If no conditional statement is given, the jump will always occur.
Examples:
Number
v1=6
Numeric Expression
v1=v7*6
@ABS[v1]>10
Array Element
v1<count[2]
Variable
v1<v2
Internal Variable
_TPX=0
_TVX>500
I/O
v1>@AN[2]
@IN[1]=0
Multiple Conditional Statements
The DMC-40x0 will accept multiple conditions in a single jump statement. The conditional statements are
combined in pairs using the operands “&” and “|”. The “&” operand between any two conditions, requires that
both statements must be true for the combined statement to be true. The “|” operand between any two
conditions, requires that only one statement be true for the combined statement to be true.
Note: Each condition must be placed in parentheses for proper evaluation by the controller. In addition, the DMC-
40x0 executes operations from left to right. See Mathematical and Functional Expressions for more information.
For example, using variables named v1, v2, v3 and v4:
JP #TEST,((v1<v2)&(v3<v4))
