Power Connector Part Numbers
Overview
The DMC-40x0 uses Molex Mini-Fit, Jr.™ Receptacle Housing connectors for connecting DC Power to the Amplifiers,
Controller, and Motors. This section gives the specifications of these connectors. For information specific to your
Galil amplifier or driver, refer to the specific amplifier/driver in the Integrated Components section.
Molex Part Numbers
There are 3 different Molex connectors used with the DMC-40x0. The type of connectors on any given controller
will be determined be the Amplifiers/Drivers that were ordered. Below are tables indicating the type of Molex
Connectors used and the specific part numbers used on each Amplifier or Driver. For more information on the
connectors, go to 366Hhttp://www.molex.com/
On Board Connector Common Mating Connectors* Crimp Part Number Type
MOLEX# 39-31-0060 MOLEX# 39-01-2065 MOLEX# 44476-3112 6 Position
MOLEX# 39-31-0040 MOLEX# 39-01-2045 MOLEX# 44476-3112 4 Position
MOLEX# 39-31-0020 MOLEX# 39-01-2025 MOLEX# 44476-3112 2 Position
*The mating connectors listed are not the only mating connectors available from Molex. See 366Hhttp://www.molex.com/ for the full list of
available mating connectors.
Galil Amplifier / Driver On Board Connector Type
None MOLEX# 39-31-0020 2 Position
AMP-43040
Power MOLEX# 39-31-0060 6 Position
Motor MOLEX# 39-31-0040 4 Position
AMP-43140
Power MOLEX# 39-31-0040 4 Position
Motor MOLEX# 39-31-0020 2 Position
SDM-44040
Power MOLEX# 39-31-0060 6 Position
Motor MOLEX# 39-31-0040 4 Position
SMD-44140
Power MOLEX# 39-31-0060 6 Position
Motor MOLEX# 39-31-0040 4 Position
Appendices ▫ 192 DMC-40x0 User Manual
