Galil Motion Control DMC-40 0 Series User Manual

Chapter 6 Programming Motion
Overview
The DMC-40x0 provides several modes of motion, including independent positioning and jogging, coordinated
motion, electronic cam motion, and electronic gearing. Each one of these modes is discussed in the following
sections.
The DMC-4010 are single axis controllers and use X-axis motion only. Likewise, the DMC-4020 use X and Y, the
DMC-4030 use X,Y, and Z, and the DMC-4040 use X,Y,Z, and W. The DMC-4050 use A,B,C,D, and E. The DMC-4060
use A,B,C,D,E, and F. The DMC-4070 use A,B,C,D,E,F, and G. The DMC-4080 use the axes A,B,C,D,E,F,G, and H.
The example applications described below will help guide you to the appropriate mode of motion.
4080
For controllers with 5 or more axes, the specifiers, ABCDEFGH, are used. XYZ and W may be interchanged
with ABCD.
EXAMPLE APPLICATION MODE OF MOTION COMMANDS
Absolute or relative positioning where each
axis is independent and follows prescribed
velocity profile.
Independent Axis Positioning
PA, PR, SP, AC, DC
Velocity control where no final endpoint is
prescribed. Motion stops on Stop command.
Independent Jogging
JG, AC, DC, ST
Absolute positioning mode where absolute
position targets may be sent to the controller
while the axis is in motion.
Position Tracking
PA, AC, DC, SP, PT
Motion Path described as incremental position
points versus time.
Contour Mode
CM, CD, DT
Motion Path described as incremental
position, velocity and delta time
PVT Mode
PV, BT
2 to 8 axis coordinated motion where path is
described by linear segments.
Linear Interpolation Mode
LM, LI, LE, VS,VR,
VA, VD
2-D motion path consisting of arc segments
and linear segments, such as engraving or
quilting.
Vector Mode: Linear and Circular Interpolation
Motion
VM, VP, CR, VS,VR,
VA, VD, VE
Third axis must remain tangent to 2-D motion
path, such as knife cutting.
Coordinated motion with Tangent Motion:
VM, VP, CR, VS,VA,VD,
TN, VE
Electronic gearing where slave axes are scaled
to master axis which can move in both
directions.
Electronic Gearing
GA, GD, _GP, GR, GM
(if gantry)
Master/slave where slave axes must follow a
master such as conveyer speed.
Electronic Gearingwith Ramped Gearing
GA, GD, _GP, GR
Chapter 6 Programming Motion ▫ 71 DMC-40x0 User Manual
