100mA – 100mA Maximum Current output for AMP-43140
The 100mA option configures the AMP-43140 (-D3140) for 10mA/V gain with a maximum current output of
100mA.
This option is only valid with the AMP-43140.
Part number ordering example: DMC-4040-C012-I000-D3140(100mA)
SSR – Solid State Relay Option for AMP-43140
The SSR option configures the AMP-43140 (-D3140) with Solid State Relays on the motor power leads that are
engaged and disengaged when the amplifier is enabled and disabled. See the -SSR Option in the AMP-43140
section of the Appendix for more information.
This option is only valid with the AMP-43140.
Part number ordering example: DMC-4040-C012-I000-D3140(SSR)
HALLF – Filtered Hall Sensor Inputs
The HALLF option will place a capacitor between the hall input and digital GND to filter unwanted noise. This
results in cleaner, more reliable hall sensor reads. The HALLF option is only available for Galil's internal PWM
amplifiers that have hall effect sensors.
Part number ordering example: DMC-4020(MO)-C012-I000-D3020(HALLF)
Appendices ▫ 191 DMC-40x0 User Manual
