Analog Inputs: AI[8:1]
±10 volts
12-Bit Analog-to-Digital converter
16-bit optional
Optoisolated Digital Outputs: DO[16:1]* 500mA Sourcing
*[8:1] for 1-4 axes models, [16:1] for 5-8 axes models
Extended I/O: IO[80:17] Configurable 0-5V TTL as Inputs or Outputs
Configured by the CO command in banks of 8
Auxiliary Inputs as Uncommitted Inputs:
DI[96:81]*
The auxiliary pins can be used as uncommitted inputs and are
assigned to the following bits:
Axis A: DI81, DI82
Axis B: DI83, DI84
Axis C: DI85, DI86
Axis D: DI87, DI88
Axis E: DI89, DI90
Axis F: DI91, DI92
Axis G: DI93, DI94
Axis H: DI95, DI96
These inputs have the same specifications as listed above for encoder
inputs.
*The number of auxiliary inputs is dependent on the number of axes ordered
Power Requirements
20-80 V
DC
12-16 W at 25° C
+5, ±12V Power Output Specifications
Output Voltage Tolerance Max Current Output
+5V
±5%
1.1A
+12V
±5%
40mA
-12V
±5%
40mA
Appendices ▫ 183 DMC-40x0 User Manual
