The DMC-2000 Daughter Board
J4
CMB-2001 REV C
USB DAUGHTER CARD
GALIL MOTION CONTROL
U9
J6
MRST XON XOF HSHK 9600 19.2 38 A2 A1 A0 USB
EXTENDED I/O
J1
J3
MADE IN USA
1
A1
B1
C1
AUX
JP4
JP3
R232 R232 R232 R485
TERM
MAIN J5
USB IN
USB OUT
TERM
R485 R232 R232 R232
R422
S 8
8 S
D1
USB Communications
Status LED
MC1489 MC1488
U7U2 U6
U1
J2
100 pin connector
(attaches to DMC-2000
Main board)
AUX Serial port
DB-9 Female
MAIN Serial port
DB-9 Male
80 pin high
density connector
for extended I/O
USB type B
connector
Configuration DIP
Switches
USB type A
connector (x2)
3.94"
7.85 "
2.53"
RS-232 buffer
IC's
Figure 2-2 - Outline of the DMC-2000 Daughter Board
10 • Chapter 2 Getting Started DMC-2X00
