Galil DMC-2X00 - DMC-2 X00 Auxiliary Encoder 36 Pin High Density Connector; DMC-2 X00 Extended I;O 80 Pin High Density Connector

43 A+H 93 nc
44 A-H 94 nc
45 B+H 95 nc
46 B-H 96 nc
47 I+H 97 nc
48 I-H 98 nc
49 +12V 99 -12v
50 +12V 100 -12v
DMC-2x00 Auxiliary Encoder 36 Pin High Density Connector
1 5v 19 5v
2 gnd 20 gnd
3 +aaX 21 +aaE
4 -aaX 22 -aaE
5 +abX 23 +abE
6 -abX 24 -abE
7 +aaY 25 +aaF
8 -aaY 26 -aaF
9 +abY 27 +abF
10 -abY 28 -abF
11 +aaZ 29 +aaG
12 -aaZ 30 -aaG
13 +abZ 31 +abG
14 -abZ 32 -abG
15 +aaW 33 +aaH
16 -aaW 34 -aaH
17 +abW 35 +abH
18 -abW 36 -abH
DMC-2x00 Extended I/O 80 Pin High Density Connector
Pin Signal Block Bit @IN[n], @OUT[n] Bit No
1 I/O 8 72 7
2 I/O 9 73 0
3 I/O 8 71 6
4 I/O 9 74 1
5 I/O 8 70 5
6 I/O 9 75 2
7 I/O 8 69 4
8 I/O 9 76 3
9 I/O 8 68 3
10 I/O 9 77 4
11 I/O 8 67 2
12 I/O 9 78 5
13 I/O 8 66 1
14 I/O 9 79 6
15 I/O 8 65 0
16 I/O 9 80 7
17 I/O 7 64 7
18 GND -- -- GND
196 • Appendices DMC-2X00
