Galil DMC-2X00 - Ethernet; Cable Connections for DMC-2 X00; Standard RS-232 Specifications

Ethernet
100 BASE-T/10 BASE-T - Kycon GS-NS-88-3.5
Pin Signal
1 TXP
2 TXN
3 RXP
4 NC
5 NC
6 RXN
7 NC
8 NC
10 BASE-2- AMP 227161-7
10 BASE-F- HP HFBR-1414 (TX, Transmitter)
HP HFBR-2416 (RX, Receiver)
LED Status
F Uses Fiber Link
C 1. On solid when using full duplex (plugged into a switch)
2. Off when using half duplex (plugged into a hub)
3. Blinks in the case of a collision
L Ethernet link established – will blink for any activity
100 Uses 100Base T speed Ethernet
Cable Connections for DMC-2x00
The DMC-2x00 requires the transmit, receive, and ground for slow communication rates. (i.e. 1200
baud) For faster rates the handshake lines are required. The connection tables below contain the
handshake lines. These descriptions and tables are for RS-232 only. RS-422 is available on request.
Standard RS-232 Specifications
25 pin Serial Connector (Male, D-type)
This table describes the pinout for standard serial ports found on most computers.
Pin Number Function
1 NC
2 Transmitted Data
3 Received Data
4 Request to Send
5 Clear to Send
DMC-2X00 Appendices y 199
