Galil DMC-2X00 - Keypad Map - Panel Mount - 6 Columns X 5 Rows

# is <Cntrl>[5,1]
Keypad Map - Panel Mount – 6 columns x 5 rows
Single Key Output
5 F1 1 2 3
4 F2 4 5 6
3 F3 7 8 9
2 F4 - 0 .
1 F5 CTRL SHIFT SPACE BKSPC ENTER
Shift Key Output
5 A F G H I J
4 B K L M N O
3 C P Q R S T
2 D U V W X Y
1 E CTRL SHIFT Z , ?
CTRL Key Output
5 (18) (19) (2) ! “ %
4 (16) * + / $ ;
3 (9) < > \ [ ]
2 (4) ^ - @ { }
1 (17) CTRL SHIFT ESC = #
NOTE: Values in parentheses are ASCII decimal values. Key locations are represented by [m,n]
where m is element column, n is element row.
Escape Commands
Escape codes can be used to control the TERM-1500 display, cursor style, and position, and sound
settings.
NOTE: The escape character (hex 1B) can be sent through port 2 of the DMC-2x00 with special
syntax {^27}:
Example: MG {P2}{^27},”H” Sends escape H to the terminal from port 2
Cursor Movement Commands
ESC A Cursor Up
ESC B Cursor Down
ESC C Cursor Right
ESC D Cursor Left
242 • Appendices DMC-2X00
