Galil DMC-2X00 User Manual

Specifications - Panel Mount
Keypad 30-Key; 5 rows x 6 columns ; 5x7 font
Display 4 row x 20 character LCD
Power 5 volts, 30mA
Keypad Maps - Hand-Held
30 Keys: 5 keys across, 6 down
Single Key Output
6 F1 (22) F2 (23) F3 (24) F4 (25) F5 (26)
5 1 2 3
4 4 5 6
3 7 8 9
2 0
1 CTRL SHIFT SPACE BKSPC ENTER
Shift Key Output
6 A B C D E
5 F G H I J
4 K L M N O
3 P Q R S T
2 U V W X Y
1 CTRL SHIFT Z , ?
CTRL Key Output
6 (18) (16) (9) (4) (17)
5 (19) (2) ! “ %
4 * + / $ ;
3 < > \ [ ]
2 ^ - @ { }
1 CTRL SHIFT ESC = #
NOTE: Values in parentheses are ASCII decimal values. Key locations are represented by [m,n]
where m is element column, n is element row.
Example:
U is <Shift>[1,2]
DMC-2X00 Appendices y 241

Galil DMC-2X00 Specifications

General

Brand	Galil
Model	DMC-2X00
Category	Controller
Language	English
