Galil DMC-2X00 - CB-50-100 Adapter Board; Connectors

REV A+B
TERMINAL #
REV C
TERMINAL #
LABEL DESCRIPTION BANK
96 96 I/OC17-24 I/O common for I/O 17-24 0
97 95 PWROUT24 Power output 24 0
98 98 PWROUT23 Power output 23 0
99 97 PWROUT22 Power output 22 0
100 100 PWROUT21 Power output 21 0
101 99 PWROUT20 Power output 20 0
102 102 PWROUT19 Power output 19 0
103 101 PWROUT18 Power output 18 0
104 104 PWROUT17 Power output 17 0
103 GND Ground
• Silkscreen on Rev A board is incorrect for these terminals.
NOTE: The part number for the 100-pin connector is #2-178238-9 from AMP.
CB-50-100 Adapter Board
The CB-50-100 adapter board can be used to convert the CABLE-100 to (2) 50 Pin Ribbon Cables.
The 50 Pin Ribbon Cables provide a versatile method of accessing the controller signals without the
use of a Galil Interconnect Module.
Connectors:
JC8 50 PIN IDC J9 100 PIN HIGH DENSITY CONNECTOR
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 10
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
19 19
20 20
230 • Appendices DMC-2X00
