REV A+B
TERMINAL #
REV C
TERMINAL #
LABEL DESCRIPTION BANK
53 51 OUTC41-48 Out common for I/O 41-48 3
54 54 I/OC41-48 I/O common for I/O 41-48 3
55 53 I/O40 I/O bit 40 2
56 56 I/O39 I/O bit 39 2
57 55 I/O38 I/O bit 38 2
58 58 I/O37 I/O bit 37 2
59 57 I/O36 I/O bit 36 2
60 60 I/O35 I/O bit 35 2
61 59 I/O34 I/O bit 34 2
62 62 I/O33 I/O bit 33 2
63 61 OUTC33-40 Out common for I/O 33-40 2
64 64 I/OC33-40 I/O common for I/O 33-40 2
65 63 I/O32 I/O bit 32 1
66 66 I/O31 I/O bit 31 1
67 65 I/O30 I/O bit 30 1
68 68 I/O29 I/O bit 29 1
69 67 I/O28 I/O bit 28 1
70 70 I/O27 I/O bit 27 1
71 69 I/O26 I/O bit 26 1
72 72 I/O25 I/O bit 25 1
73 71 OUTC25-32 Out common for I/O 25-32 1
74 74 I/OC25-32 I/O common for I/O 25-32 1
75 73 OUTC25-32 Out common for I/O 25-32 1
76 76 I/OC25-32 I/O common for I/O 25-32 1
77 75 PWROUT32 Power output 32 1
78 78 PWROUT31 Power output 31 1
79 77 PWROUT30 Power output 30 1
80 80 PWROUT29 Power output 29 1
81 79 PWROUT28 Power output 28 1
82 82 PWROUT27 Power output 27 1
83 81 PWROUT26 Power output 26 1
84 84 PWROUT25 Power output 25 1
85 83 I/O24 I/O bit 24 0
86 86 I/O23 I/O bit 23 0
87 85 I/O22 I/O bit 22 0
88 88 I/O21 I/O bit 21 0
89 87 I/O20 I/O bit 20 0
90 90 I/O19 I/O bit 19 0
91 89 I/O18 I/O bit 18 0
92 92 I/O17 I/O bit 17 0
93 91 OUTC17-24 Out common for I/O 17-24 0
94 94 I/OC17-24 I/O common for I/O 17-24 0
95 93 OUTC17-24 Out common for I/O 17-24 0
DMC-2X00 Appendices y 229
