REV A+B
TERMINAL #
REV C
TERMINAL #
LABEL DESCRIPTION BANK
10 10 I/O75 I/O bit 75 7
11 9 I/O74 I/O bit 74 7
12 12 I/O73 I/O bit 73 7
13 11 OUTC73-80 Out common for I/O 73-80 7
14 14 I/OC73-80 I/O common for I/O 73-80 7
15 13 I/O72 I/O bit 72 6
16 16 I/O71 I/O bit 71 6
17 15 I/O70 I/O bit 70 6
18 18 I/O69 I/O bit 69 6
19 17 I/O68 I/O bit 68 6
20 20 I/O67 I/O bit 67 6
21 19 I/O66 I/O bit 66 6
22 22 I/O65 I/O bit 65 6
23 21 OUTC65-72 Out common for I/O 65-72 6
24 24 I/OC65-72 I/O common for I/O 65-72 6
25 23 I/O64 I/O bit 64 5
26 26 I/O63 I/O bit 63 5
27 25 I/O62 I/O bit 62 5
28 28 I/O61 I/O bit 61 5
29 27 I/O60 I/O bit 60 5
30 30 I/O59 I/O bit 59 5
31 29 I/O58 I/O bit 58 5
32 32 I/O57 I/O bit 57 5
33 31 OUTC57-64 Out common for I/O 57-64 5
34 34 I/OC57-64 I/O common for I/O 57-64 5
35 33 I/O56 I/O bit 56 4
36 36 I/O55 I/O bit 55 4
37 35 I/O54 I/O bit 54 4
38 38 I/O53 I/O bit 53 4
39 37 I/O52 I/O bit 52 4
40 40 I/O51 I/O bit 51 4
41 39 I/O50 I/O bit 50 4
42 42 I/O49 I/O bit 49 4
43 41 OUTC49-56 Out common for I/O 49-56 4
44 44 I/OC49-56 I/O common for I/O 49-56 4
45 43 I/O48 I/O bit 48 3
46 46 I/O47 I/O bit 47 3
47 45 I/O46 I/O bit 46 3
48 48 I/O45 I/O bit 45 3
49 47 I/O44 I/O bit 44 3
50 50 I/O43 I/O bit 43 3
51 49 I/O42 I/O bit 42 3
52 52 I/O41 I/O bit 41 3
