20 (Data Terminal Ready) 4
7 (Signal Ground) 5
Controller Ground 9
Cable to Connect Computer 9 pin to Main Serial Port Cable (9 pin)
9 Pin (FEMALE - Computer) 9 Pin (FEMALE - Controller)
1 (Carrier Detect) 1
2 (Receive Data) 2
3 (Transmit Data) 3
4 (Data Terminal Ready) 4
5 (Signal Ground) 5
Controller Ground 9
Cable to Connect Computer 25 pin to Auxiliary Serial Port Cable (9
pin)
25 Pin (Male - terminal) 9 Pin (male - controller)
20 (Data Terminal Ready) 1
2 (Transmit Data) 2
3 (Receive Data) 3
8 (Carrier Detect) 4
7 (Signal Ground) 5
Controller +5V 9
Cable to Connect Computer 9 pin to Auxiliary Serial Port Cable (9 pin)
9 Pin (FEMALE - terminal) 9 Pin (MALE - Controller)
4 (Data Terminal Ready) 1
3 (Transmit Data) 2
2 (Receive Data) 3
1 (Carrier Detect) 4
5 (Signal Ground) 5
Controller +5V 9
DMC-2X00 Appendices y 201
