Switching
13 · G&D DVIMUX2-DL-USB
Switching by mouse
How to switch the active channel by mouse:
Press and hold mouse key 4 (usually: Back).
Move the mouse to the left or to the right to switch the channel in ascending or
descending order.
Switching via serial device
The channels can be switched via a serial device connected to the RS232 port of the
KVM switch.
The serial device can either be a special keypad or a computer which
is terminal emulator operated
.
Connection settings
Use the following connection settings for the serial end device to establish a serial
connection to the KVM switch.
Bits per second: 115.200 (to switch the bitrate, see pages 37)
Data bits: 8
Parity: none
Stop bits: 1
Flow control: none
IMPORTANT:
Switching by mouse is disabled in the default settings of the KVM
switch default. Information about how to activate the function is given on
page 32.
NOTE:
If the Single mode is active, you can switch only to the next or the prior
channel.
Switching across several channels requires the Multiple mode.
NOTE:
To connect the serial device, use the optional device connection cable
CC-Link-2 (item no. A6200093)
IMPORTANT:
Use the following connection settings and the switching commands of
the KVM switch to successfully switch the channel with a serial end device.
