Configuration
37 · G&D DVIMUX2-DL-USB
Changing the bitrate of the RS232 port
The RS232 port transfers a certain amount of data per time unit. The bitrate is given
in bit/s.
If the bitrate cannot be adjusted to the standard bitrate of the KVM switch (115.200
bit/s) in the terminal emulator or the serial device, the bitrate of the RS232 port can
be modified.
How to select the bitrate of the RS232 port of the KVM switch:
IMPORTANT:
Transmitter and receiver of the data must use the same bitrate to
ensure successful communication between the terminal emulator or a serial device
and the KVM switch.
Setup Menu
1. Use the terminal emulator to establish a connection to the KVM switch.
If the setup menu is not displayed, the Monitoring mode of the service port is
enabled. Enter
»!« to switch to the setup menu.
2. Use the Arrow or Arrow keys to select RS232 Port Config and press Enter.
3. Use the Arrow or Arrow keys to select the row Bitrate.
4. Press the Space key (repeatedly) to select between the following bitrates:
9600
19200
38400
57600
115200 (default)
230400
5. After having selected your desired settings, press Q to leave the dialog.
6. Press the S key to save your settings.
