Monitoring
17 · G&D DVIMUX2-DL-USB
The string issued by the KVM switch has the following meaning:
Byte(s) Value Meaning
1 2 G&D monitoring protocol
2 A Monitoring takes place via Service port
B Monitoring takes place via RS232 port
3 A KVM signals switched to channel 1
B KVM signals switched to channel 2
4 A USB 2.0 devices switched to channel 1
B USB 2.0 devices switched to channel 2
5 k USB keyboard detected at the bottom »USB-Keyb./Mouse« port
m USB mouse detected at the bottom »USB-Keyb./Mouse« port
h USB hub detected at the bottom »USB-Keyb./Mouse« port
u Unknown device detected at the bottom »USB-Keyb./Mouse« port
- No compatible device detected at the bottom »USB-Keyb./Mouse« port
6 k USB keyboard detected at the top »USB-Keyb./Mouse« port
m USB mouse detected at the top »USB-Keyb./Mouse« port
h USB hub detected at the top »USB-Keyb./Mouse« port
u Unknown device detected at the top »USB-Keyb./Mouse« port
- No compatible device detected at the top »USB-Keyb./Mouse« port
7-22 String Firmware version of the KVM switch
Example: V1.00.008(00067)
23 P The computer connected to interface »CPU 1« is ready for operation.
- No computer is connected to interface »CPU 1« or the computer is turned off.
24 s Incoming VGA signal detected at interface »CPU 1«
- No incoming VGA signal detected at interface »CPU 1«
25 E The USB KM emulation for CPU 1 has been initialised by USB host.
U The USB KM emulation for CPU 1 has detected the USB host.
- The USB KM emulation for CPU 1 has not detected a USB host.
26 P The computer connected to interface »CPU 2« is ready for operation.
- No computer is connected to interface »CPU 2« or the computer is turned off.
27 s Incoming VGA signal detected at interface »CPU 2«
- No incoming VGA signal detected at interface »CPU 2«
