Garmin ECHOMAP UHD User Manual

Specifications
All Models
Specification Measurement
Material Polycarbonate plastic
Water rating IEC 60529 IPX7
6
Temperature range From -15° to 55°C (from 5° to 131°F)
Input voltage From 9 to 18Vdc
Fuse 3A, 125V fast-acting
Compass-safe distance 65cm (25.6in.)
NMEA 2000 LEN @ 9Vdc 1
NMEA 2000 draw 75mA max.
Memory card 1 microSD card slot; 32 GB max. card size
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
6-Inch Models
Specification Measurement
Dimensions on cradle and bail mount with swivel base (W x H x D) 21.8 x 13.0 x 6.2cm (8.6 x 5.1 x 2.6 in.)
Display size (W x H)
13.7 x 7.7cm (5.4 x 3.1in.)
15.2cm (6.2in.) diagonal
Display resolution WVGA, 400 x 800pixels
Weight 0.75kg (1.6lb.)
Compass-safe distance 65cm (25.6in.)
Clearance to nearest obstruction 8.0cm (3.14in.)
Max. power draw 12W
Typical current draw at 12Vdc (RMS) 0.7A
Max. current draw at 12Vdc 1.25A
Wireless frequency 2.4 GHz @ 17.2 dBm maximum
6
The device withstands incidental exposure to water of up to 1m for up to 30min. For more information, go to www.garmin.com/waterrating.
Appendix 117

Garmin ECHOMAP UHD Specifications

General

Water Rating	IPX7
Routes	100
Sonar	Yes (CHIRP, ClearVü, SideVü)
GPS	Yes
Preloaded Maps	Yes
Network Support	Yes, Garmin Marine Network
Wi-Fi	Yes
Mounting Options	Flush mount
Antenna	Internal
Transmitter Power	500W (RMS), 4000W (peak to peak)
Sonar Frequencies Supported	ClearVü/SideVü: 260/455/800 kHz
Maximum Depth	2, 300 ft (freshwater)
Wireless Connectivity	Wi-Fi
