5 Place the handlebar connector around the rubber pad.
6 Replace and tighten the screw.
NOTE: Garmin
®
recommends a torque specification of 7 lbf-in. (0.8 N-m).
You should check the tightness of the screw periodically.
7 Align the tabs on the back of the Edge device with the bike mount notches
5
.
8 Press down slightly and turn the Edge device clockwise until it locks into
place.
Releasing the Edge
1 Turn the Edge clockwise to unlock the device.
2 Lift the Edge off the mount.
