NMEA 0183 with Audio Cable Pinout
The NMEA 0183 with audio cable (010-12852-00 or 010-12390-21) includes bare wires and an RCA connector
for an audio out connection to a stereo, including Fusion stereos. You can purchase this cable from garmin.com
or your local Garmin dealer.
After installing the cable, you can connect the RCA connectors to the AUX input of the stereo. The HDMI input is
then output to the stereo.
The cable also provides NMEA 0183 inputs and outputs.
Model Accessory Part Number NMEA 0183 Inputs and Outputs
10 inch 010-12852-00 One differential input and output port
12 inch 010-12852-00 One differential input and output port
16 inch 010-12852-00 One differential input and output port
17 inch 010-12390-21 Four input ports and two output ports
22 inch 010-12390-21 Four input ports and two output ports
24 inch 010-12390-21 Four input ports and two output ports
8700 black box 010-12390-21 (included) Four input ports and two output ports
Appendix 175
