Garmin GPSMAP8412 - Specifications; GPSMAP 8 X10 Specifications

Specifications
GPSMAP 8x10 Specifications
Dimensions (W × H × D) 259.9 × 205.1 × 75.1.mm (10
1
/
4
× 8
1
/
16
× 2
15
/
16
in.)
Dimensions on bail mount (W × H × D) 259.9 × 221.6 × 103.5.mm (11
1
/
16
× 8
3
/
4
× 4
1
/
16
in.)
Display size (W × H)
218.4 × 136.9 mm (8
5
/
8
× 5
3
/
8
in.)
10 in. diagonal
Display resolution WUXGA, 1920 × 1080 pixels
Weight 2.4 kg (5.2 lb.)
Compass-safe distance 45 cm (17.7 in.)
Clearance behind flush-mounted device 11.1 cm (4
3
/
8
in.)
Temperature range From -15° to 55°C (from 5° to 131°F)
Material Polycarbonate plastic and die-cast aluminum
Water rating
IEC 60529 IPX7
The device withstands incidental exposure to water of up to 1 m for
up to 30 min. For more information, go to www.garmin.com/water
rating.
Fuse 10 A, 125 V fast-acting
Input voltage From 10 to 32 Vdc
Max. power usage at 10 Vdc 40.1 W
Typical current draw at 12 Vdc 1.5 A
Max. current draw at 12 Vdc 6.0 A
NMEA 2000 LEN @ 9 Vdc 2
NMEA 2000 draw 75 mA max.
Max. waypoints 5,000
Max. routes 100 (250 waypoints each)
Max. active track points 50,000 points, 50 saved tracks
Memory card 2 microSD card slots in the back of the device; 32 GB max. card size
Wireless frequency and protocols
Wi‑Fi and ANT
®
technologies
2.4 GHz @ 12.3 dBm nominal
HTML integration Compatible with OneHelm
™
integration
Appendix 181
