3 PRODUCT OVERVIEW
3.1 CHARGING STATION SYSTEM OVERVIEW
A. Installation bracket. The installation bracket is
available as single and double (side by side).
B. Charging unit. The charging unit is available in
several versions. Refer to 3.3 Product variants, page
13. The fixed cable (B1) or Type 2 outlet (B2) can be
positioned on either side of the charging unit.
C. Front cover for charging units without an MID
certified, visible energy meter. The front cover is
available in several colors.
D. Front cover for charging units with an MID certified,
visible energy meter. The front cover is available in
several colors.
E. Protection cover. The protection cover is an
accessory that is used for a prepared installation
without an attached charging unit.
Garo offers various installation accessories. Both as a
complete charging station or as individual system
components.
A B
B1 B2
C
D
E
Version: 1.3 11
Product overview
