GARO ENTITY PRO - Load Interface Technical Data

Power connection terminals 2.5–16 mm
2
, spring type
Warranty 2 years
Design product life cycle 10 years installation/30 000 hours charging at 20 C
Appliance class. Protection against electric shock Class I equipment with PE connection
8.2 LOAD INTERFACE TECHNICAL DATA
Standards EN 62368-1
EMC Classification 2014/30/EU
Installation method DIN rail.
Installation environment Indoor/outdoor electrical cabinet.
Location type Restricted access.
Rated voltage TN/IT/TT 1-phase 230 VAC 50 Hz
Rated current 13 mA
Installation systems TN, IT and TT system.
Power <3W
Protection class IP20. Appliance class protection against electric shock:
Class II.
Connection terminals 1.5 mm
2
, spring type.
Temperature range -20 °C to +50 °C
Weight 0.2 kg
Dimensions (heightxwidthxdepth) 86x72x49 + antenna 110 mm (4 DIN modules).
Color Grey
Recommended protective pre-fuse max. C 10 A
Overvoltage category III (OVC 3)
Version: 1.3 97
Technical data
