Weight 3-3.7 kg without cable (depending on product variant)
Cable length (fixed cable version) 4.5 m/5 m/8 m
NOTE
IEC 61851-1 allows max. 7.5 m.
Size single version charging station, height*width*depth 340*240*150 mm
Size double version charging station,
height*width*depth
340*495*145 mm
Residual current limit 30mA AC/6mA DC
Rated short-time withstand current 10 kA
Rated conditional short-circuit current of an assembly 10 kA
Short-circuit protective device type C
Rated impulse withstand voltage 4 kV
Rated insulation voltage 230 V/400 V
Over voltage category III
Rated diversity factor (RDF) 1
Pollution degree 2
EMC environmental condition A
RFID Frequency Band 13.56 MHz
RFID output power 300 mW
SIM 3 FF = Micro = 15x25 mm
Modem Lte Cat M1/Cat Nb2/Egprs
Wi-Fi 802.11 g 2.5 GHz
Maximum pre-fuse to terminal 80 A Char. C
Installation power cable limitations Maximum area: 16 mm
2
, outer diameter: maximum 24
mm
96 Version: 1.3
Technical data
