21 TECHNICAL DATA
104
Screw, water pump cover M6 10 Nm (7.4 lbf ft)
Screw, cylinder head M7 18 Nm (13.3 lbf ft)
Nuts, cylinder base M8 20 Nm (14.8 lbf ft)
Screw, clutch basket M8 35 Nm (25.8 lbf ft)
Stud bolt, cylinder base M8 10 Nm (7.4 lbf ft)
Spark plug M10x1 10 … 12 Nm (7.4 … 8.9 lbf ft)
Nut, primary gear wheel M10x1.25 40 Nm (29.5 lbf ft)
Loctite
®
243™
Nut, rotor M10x1.25 15 Nm (11.1 lbf ft)
Loctite
®
243™
Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
21.3 Carburetor with carburetor tuning
Carburetor type Dell`Orto PHBG 19BS
Needle position 2nd position from top
Idle air adjusting screw
Open 3 turns
Main jet 95
Jet needle W7
Idling jet 50
Needle jet 262AU
Throttle slide 40
Choke nozzle 60
21.4 Capacities
21.4.1 Gear oil
Gear oil 0.20 l (0.21 qt.)
Gear oil (ATF Dexron 3) ( p. 109)
21.4.2 Coolant
Coolant 0.7 l (0.7 qt.)
Coolant ( p. 108)
21.4.3 Fuel
Fuel tank capacity, approx. 2.3 l (2.4 qt.) Super unleaded (95 octane) mixed with
2-stroke engine oil (1:60) ( p. 109)
21.5 Chassis
Frame Central tube frame of chrome molybdenum steel tubing,
powder-coated
Fork WP XACT 5235
Shock absorber WP XACT 5735
Suspension travel
front 205 mm (8.07 in)
rear 185 mm (7.28 in)
Fork offset 22 mm (0.87 in)
Brake system
