SIGA-REL programming
QS4 Technical Reference Manual C.3
Programming instructions
¨
¨¨
¨ Read me first
WARNING: Attempting to program this application without a
complete understanding of the operation of the SIGA–REL, the
latest technical information, and the consequences of exposing
someone to fire suppression agents may cause personal injury,
event death.
WARNING: Improper application of fire suppression agents can
lead to property damage, serious injury, or loss of life. Consult
the applicable NFPA documents and the local authority having
jurisdiction (AHJ) for more information.
WARNING: Disabled and Service Group points will not prevent
activation of the release circuits.
This application requires the operation of at least two automatic
detectors to activate the fire suppression system. In order to
meet NFPA 72 requirements, you must program an And group
with at least two smoke detectors and a minimum activation
count of 2. The smoke detectors must have their Primary and
Alternate Verification properties set to None.
The SIGA–REL has six addressable circuits. To add the SIGA–
REL to the loop controller database you must add three SIGA–
RELs. The first SIGA–REL is for the Abort switch and Manual
Release switch circuits, the second for the two release circuits,
and the third for the two prerelease circuits.
Perform these instructions in order from beginning to end.
Check the check box provided as you complete each step.
As a safety precaution, disconnect releasing devices from
SIGA–REL TB4 before downloading setup data to the loop
controller.
¨
¨¨
¨ Add the Abort and Manual
Release Switch circuits
Note: Enter the information exactly as
shown to ensure that you program the
application according to manufacturer's
specifications.
1. Click Configure, then click Cabinets.
2. Select the SLIC connected to the SIGA–REL then click
Configure.
3. Click the Modules tab, then set the Quantity box to 1.
4. Enter the following information:
Device Type: Monitor
Model: REL
Personality: (3) Active B
Message Specification: SIGA–REL1 A001 and ABORT SW
2nd Device Type: Pull
2nd Personality: (1) Alarm B
2nd Message Specification: SIGA–REL1 A002 and MAN
RELEASE SW
5. Click Add.
