GE 735

4-14 735/737 Feeder Protection Relay
GE Power Management
4.3 MEMORY MAP 4 MODBUS COMMUNICATIONS
4
F107
continued
CURVE SHAPE SWITCH
continued
Very Inverse (hi
g
h) = 8
Extremely Inverse (low) = 9
Extremely Inverse (hi
g
h) = 10
F108 PHASE PICKUP SWITCH OFF = 1
20 = 2
30 = 3
40 = 4
50 = 5
60 = 6
70 = 7
80 = 8
90 = 9
100 = 10
110 = 11
120 = 12
130 = 13
140 = 14
150 = 15
160 = 16
180 = 17
200 = 18
220 = 19
F109 PHASE INSTANTANEOUS DIAL OFF = 1
4 = 2
5 = 3
6 = 4
8 = 5
10 = 6
12 = 7
14 = 8
16 = 9
20 = 10
F110 Ground fault pickup OFF = 1
15 = 2
20 = 3
25 = 4
30 = 5
35 = 6
40 = 7
45 = 8
50 = 9
55 = 10
Table 4–2: 735/737 MEMORY MAP DATA FORMATS (Sheet 3 of 5)
FORMAT TYPE DESCRIPTION
