4.3 MEMORY MAP 4 MODBUS COMMUNICATIONS
4
F114 CURVE SHIFT SETPOINT XXXX XXXX XXXX XXX1 = Switch 8 on = 1
XXXX XXXX XXXX XX1X = Switch 7 on = 1
XXXX XXXX XXXX X1XX = Switch 6 on = 1
XXXX XXXX XXXX 1XXX = Switch 5 on = 1
XXXX XXXX XXX1 XXXX = Switch 4 on = 1
XXXX XXXX XX1X XXXX = Switch 3 on = 1
XXXX XXXX X1XX XXXX = Switch 2 on = 1
XXXX XXXX 1XXX XXXX = Switch 1 on = 1
F115 LAST OC TRIP TIME 0 to 65000 = Actual Trip Time
65001 = Trip time > 65 seconds
65535 = Time not available
F116 CURVE SHAPE 0 = ANSI
1 = IAC
2 = IEC/BS142
F117 BLOCK INSTANTANEOUS 0 = DISABLED
1 to 180 seconds
F118 AUX TRIP RELAY 0 = Main Trip
1 = 86 Lockout
2 = Ground Trip
Table 4–2: 735/737 MEMORY MAP DATA FORMATS (Sheet 5 of 5)
FORMAT TYPE DESCRIPTION
