GFK-1322A Chapter 1 Overview 1-5
1
Bus Interface Module Overview
The LBIM is a standard, rack-mounted Series 90-30 PLC module. (The table on page 1-10 lists
compatible CPUs.) The module plugs easily into the PLC’s backplane or into a remote PLC
baseplate. The latch on the bottom of the module secures it in position.
There are no DIP switches or jumpers to set on the LBIM. It is configured using the IOPEN.EXE
configuration software, provided with the module on floppy disk. Procedures for configuration are
provided in Chapter 4.
PWR
a45599
LONWORKS
Bus
SVC
Interface
Module
OUT
MSG
IN
MSG
SERVICE
COM
PORT
RS-422
N
E
T
W
O
R
K
Figure 1-3. Series 90 PLC L
ON
W
ORKS
Bus Interface Module
