5-2 Series 90™-30 PLC L
LONWORKS® Bus Interface Module
User's Manual – June 1997 GFK-1322A
5
Startup and Configuration
The following table lists symptoms, causes and corrective actions for problems that could occur
while the LBIM is being powered up or during configuration.
Table 5-1. Troubleshooting
Symptom Cause Corrective Action
SVC indicator flashing. The LBIM is in a L
ON
W
ORKS
unconfigured state.
Complete the LBIM
configuration. (For configuration
procedures, see Chapter 4.)
IN MSG and OUT MSG
indicators flashing alternately
every second
EEPROM checksum error Power cycle the LBIM.
Incorrect PLC backplane
initialization
Errors during initialization of the
L
ON
W
ORKS
network interface
Incorrect network interface
configuration
Check for overlaps in the network
variable mapping and correct the
mapping if necessary. Download
the configuration again and power
cycle the LBIM.
IN MSG and OUT MSG
indicators flashing together
L
ON
W
ORKS
wink function
implemented. This feature is used
to facilitate installation of the
LBIM on the L
ON
W
ORKS
network.
None. This does not indicate a
problem.
When you attempt to download
the configuration .XIF file, the
following message appears:
Error opening network
driver:...
Network driver not installed. Install network driver.
Module continuously transmits
network traffic.
Max_Send_Time set too low. Change Max_Send_Time to a
larger value for all but critical
variables.
Data does not transfer to CPU
and/or PLC I/O Fault tables show
LOSS/ADD Faults.
Configuration mismatch Change backplane
configuration to match that of
the module exactly. Be sure to
account for reserved space and
valid bits.
(See Chapter 4)
