GE 90*-30 PLC Series User Manual

GFK-1322A Chapter 1 Overview 1-7
1
Connectors
During normal operation, the only external connection to the LBIM is the network connection to
the two-pin removable header on the front panel. The RJ-45 connector is reserved for easy
connection of network management tools during configuration of the interface and binding of
network variables. The RS-422 serial port is used to update LBIM firmware and is not normally
needed by the user.
Table 1-4. LBIM Connectors
Connector Function Type
NETWORK Connection of network
management tools
RJ-45
NetA, NetB
NETWORK Provides L
ON
W
ORKS
network
field connection (NETA, NETB)
using 18-24 AWG (0.86mm
2
to
0.22mm
2
) twisted pair wires.
2-pin removable screw terminal
COM PORT RS-422 RS-422 serial port that supports
SNP communications (SNP and
SNPX). Used to update LBIM
firmware. (Does not support
Hand-Held Programmer.)
DB-15, female
Series 90-30 backplane Connection to PLC backplane 24-pin connector
Table 1-5. Pin Assignments for RS-422 Port
Pin Signal Name Pin Signal Name
1 Shield 8 CTS (B)
2 No connection 9 RT
3 No connection 10 RD (A)
4 No connection 11 RD (B)
5 No connection 12 SD (A)
6 RTS (A) 13 SD (B)
7 OV 14 RTS (B)
15 CTS (A)
