GE 90*-30 PLC Series User Manual

GFK-1322A Q-1
Quick Start Guide
This Quick Start Guide describes the steps necessary to get your Series 90™ PLC L
ON
W
ORKS
®
Bus Interface Module (PE693BEM350, 351, and 352) up and running quickly. It assumes that you
have a working knowledge of L
ON
W
ORKS
network technology and GE Series 90-30 PLCs.
If you are unfamiliar with L
ON
W
ORKS
networks or with Series 90-30 PLCs, please refer to the
detailed instructions in the appropriate chapters in this manual and in the related documentation.
This chapter covers the following topics:
 Module Description ...................................................................................................Q-2
 What You Need to Operate the Bus Interface Module ................................................Q-6
 Hardware Installation and Powerup ...........................................................................Q-7
 Module Configuration/Network Installation...............................................................Q-8
 PLC Configuration ..................................................................................................Q-11
 Summary.................................................................................................................Q-12
Related Documentation
Series 90™-30 Programmable Controller Installation Manual (GFK-0356)
Logicmaster™ 90 Series 90-30/20/Micro Programming Software User’s
Manual (GFK-0466).
L
ON
W
ORKS
Installation Overview (005-0006-01)
For references to additional publications that may be helpful, refer to the
Preface in this manual.
