3-6 Series 90™-30 PLC LONWORKS® Bus Interface Module User's Manual – June 1997 GFK-1322A
3
RS-232
IC690CBL702
SLTA
To LonWorks network
Twisted Pair Cable
22
(
0.36mm
2
)
or
24
(
0.22mm
2
)
IB M PC
IBM PCwith PCLTA card
TP/XT 1250,
TP/XT 78, or
FTT-10
PCLTA Card
To LonWorks network
RS-232
IC690CBL702
IBM PCwith PCLTA card
PCMIA Card
To LonWorks network
PCC-10
RS-232
IC690CBL702
Use with PE693BEM350 (free topolo
g
y) LBIM only.
Figure 3-5. Computer to L
ON
W
ORKS
Network Connections for LBIM Configuration
