Step Action
3 Disconnect the flow kit sensors from the system.
4 Make sure to fit caps to all sensor connections on the system with the caps
p
rovided on the system.
5 Disconnect and remove customer tubing.
6 Set the switch to Flowkit install to open the pinch valves, and press Re-
set.
7 Remove the flow kit sections starting from the outlet/column side by
opening the pinch valves locking pins one by one as the tubing is removed
from the valve. Close each valve after the tubing is removed.
8 Dispose of the filled flow kit and column in accordance with local regula-
tions.
Alternative 2 - Drain and remove
t
he flow kit by section
To drain the flow kit, and then remove each section of the flow kit follow the instruc-
tions below.
NOTICE
T
he inlets and pump sections are not entirely drained using this
procedure, therefore splashing is to be expected.
Step Action
1 Connect a drain tube to the C
olumn bottom outlet tubing and lead it to a
suitable waste container.
2 Close any valves to tanks leading to the system inlets.
3 Set the switch to Drain, and press Reset.
4 When no more waste is noticed, disconnect and remove customer tubing
from the Column bottom outlet.
6 Operation
6
.3 Controlled shutdown and removal of flow kit
140
ÄKTA ready XL Operating Instructions 29281616 AE
