5 Operating procedures
36 GE Healthcare 86500-IMG rev 3
3 Slide (do not throw) the cassette in until the lock key returns to its
normal position. Take care not to trap your fingers in between the
cassette holder and the cassette.
Diamond has an automatic
cassette loading mechanism that
moves the cassette to correct
position at the front edge of the
cassette holder, ready for exposure.
In case the cassette is inside, but in
the back of the Bucky, pulling the
cassette latch towards the front of
the Bucky takes the cassette to the
front for an exposure.
NOTE!
Diamond is configured to use daylight cassettes as standard.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
