2 Operating controls
86500-IMG rev 3 GE Healthcare 5
2 Operating controls
Fig 2.1. The stand
1 X-ray tube 10 Patient hand grip
2 Diaphragm/collimator 11 C-Arm rotation buttons
3 Face shield 12 Vertical movement buttons
4 Position Control Center
control buttons (refer to
Figure 2.4)
13 ParkBack control buttons
5 Compression paddle 14 Pre-programmable C-Arm
angle buttons
6 Cassette holder 15 Mains switch (automatic trip
switch at the rear)
7 Manual compression wheels 16 User power On/Off switch
8 Compression paddle release
button
17 Emergency stop buttons, one
on each side
9 Cassette release button 18 Tube head stereoangulation
buttons
