4-46 F35 MULTIPLE FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL

FRONT PANEL INTERFACE CHAPTER 4: INTERFACES

To set up and use the label removal tool:

1. Bend the tabs at the left end of the tool upwards as shown.

Bend the tab at the center of the tool tail as shown.

To remove the LED labels from the F35 front panel and insert the custom labels:

1. Use the knife to lift the LED label and slide the label tool underneath. Ensure that the bent tabs are pointing away from

the relay.
