CHAPTER 6: ACTUAL VALUES STATUS
F35 MULTIPLE FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 6-11
6
6.3.20 Incipient fault detector
ACTUAL VALUES  STATUS  INCIPIENT FAULT  INCIPIENT FAULT 1(6)
The number of detected incipient faults for each incipient fault element are displayed here for each phase. These values
can be reset to zero with the
COMMANDS  CLEAR RECORDS  CLEAR INCIPENT FAULT COUNTERS command.
6.3.21 Remaining connection status
ACTUAL VALUES  STATUS  COMM STATUS REMAINING CONNECT
These values specify the remaining number of TCP connections still available for each protocol. The display depends on the
options applicable to your device. Each time a connection is used, the remaining number of connections decrements.
When released, the remaining number of connections increments. If no connection is made over the specific protocol, the
number equals the maximum number available for the specific protocol.
For example, the maximum number of Modbus TCP connections is 4. Once an EnerVista session is opened on a computer
connected to the UR over Ethernet, the Modbus TCP status shows 3. If the EnerVista application is closed, the Modbus TCP
status shows 4.
For the graphical front panel, the remaining connections refer to TCP connections only.
MMS TCP — The number of IEC 61850 connections remaining.
6.3.22 Parallel Redundancy Protocol (PRP)
The Parallel Redundancy Protocol (PRP) defines a redundancy protocol for high availability in substation automation
networks.
ACTUAL VALUES  STATUS  PRP STATUS
 INCIPIENT FAULT 1


INCIPIENT FAULT 1
PH A FAULTS: 0
Range: 0 to 65535 in steps of 1

INCIPIENT FAULT 1
PH B FAULTS: 0
Range: 0 to 65535 in steps of 1

INCIPIENT FAULT 1
PH C FAULTS: 0
Range: 0 to 65535 in steps of 1
 COMM STATUS
 REMAINING CONNECT

MMS TCP(max 5)
5
Range: 0 to 5

MODBUS TCP (max 4)
4
Range: 0 to 4

DNP TCP(max 2)
2
Range: 0 to 2

IEC-104 TCP(max 2)
2
Range: 0 to 2

SFTP (max 4)
4
Range: 0 to 4
 PRP STATUS


Total Rx Port A:
0
Range: 0 to 4G, blank if PRP disabled

Total Rx Port B:
0
Range: 0 to 4G, blank if PRP disabled

Mismatches Port A:
0
Range: 0 to 4G, blank if PRP disabled

Mismatches Port B:
0
Range: 0 to 4G, blank if PRP disabled
