CHAPTER 6: ACTUAL VALUES METERING

F35 MULTIPLE FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 6-17

The metered phase current values are displayed in this menu. The "SRC 1" text gets replaced by whatever name was

programmed by the user for the associated source (see

SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).

6.4.2.3 Ground current metering

ACTUAL VALUES  METERING  SOURCE SRC 1  GROUND CURRENT

The metered ground current values are displayed in this menu. The "SRC 1" text is replaced by the name programmed by

the user for the associated source (see

SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).

6.4.2.4 Phase voltage metering

ACTUAL VALUES  METERING  SOURCE SRC 1  PHASE VOLTAGE



SRC 1 PHASOR In:

0.000 A 0.0°



SRC 1 ZERO SEQ I0:

0.000 A 0.0°



SRC 1 POS SEQ I1:

0.000 A 0.0°



SRC 1 NEG SEQ I2:

0.000 A 0.0°

 GROUND CURRENT

 SRC 1



SRC 1 RMS Ig:

0.000 A



SRC 1 PHASOR Ig:

0.000 A 0.0°



SRC 1 PHASOR Igd:

0.000 A 0.0°

 PHASE VOLTAGE

 SRC 1



SRC 1 RMS Vag:

0.00 V



SRC 1 RMS Vbg:

0.00 V



SRC 1 RMS Vcg:

0.00 V



SRC 1 PHASOR Vag:

0.000 V 0.0°



SRC 1 PHASOR Vbg:

0.000 V 0.0°



SRC 1 PHASOR Vcg:

0.000 V 0.0°



SRC 1 RMS Vab:

0.00 V



SRC 1 RMS Vbc:

0.00 V



SRC 1 RMS Vca:

0.00 V



SRC 1 PHASOR Vab:

0.000 V 0.0°



SRC 1 PHASOR Vbc:

0.000 V 0.0°
