CHAPTER 7: COMMANDS AND TARGETS TARGETS
F35 MULTIPLE FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 7-7
7
• Latched target message: No.
• Description of problem: The
PRODUCT SETUP INSTALLATION RELAY SETTINGS setting indicates the F35 is not
programmed.
• How often the test is performed: On power up and whenever the
PRODUCT SETUP INSTALLATION RELAY SETTINGS
setting is altered.
• What to do: Program all settings and then set PRODUCT SETUP INSTALLATION RELAY SETTINGS to “Programmed.”
• Latched target message: No.
• Description of problem: Internal recovery failure detected.
• How often the test is performed: Continuous.
• What to do: Extract a Service Report through UR Setup software. Contact technical support and supply details of the
failure code on the display.
• Latched target message: Yes.
• Description of problem: Module hardware failure detected.
• How often the test is performed: Module dependent.
• What to do: Extract a Service Report through UR Setup software. Contact technical support and supply details of the
failure code on the display.
7.2.2.3 Minor self-test error messages
Most of the minor self-test errors can be disabled. See the settings in the User-programmable Self-tests section in chapter
5.
• Latched target message: Yes.
• Description of problem: Internal process disruption detected.
• How often the test is performed: Module dependent.
• What to do: Extract a Service Report through UR Setup software. Contact technical support and supply details of the
failure code on the display.
• Latched target message: Yes.
• Description of problem: The battery is weak or not functioning. It powers the real time clock. This message displays as
Battery Fail in the event records. When the battery weakness reaches a critical level, the message displays persistently
on the front panel and no front panel key navigation is possible.
• How often the test is performed: The battery is monitored every five seconds. The error message displays after 60
seconds if the problem persists.
• What to do: Replace the battery as outlined in the Maintenance chapter.
UNIT NOT PROGRAMMED:
Check Settings
DIAGNOSTIC FAILURE___:
Self Test Error
SYSTEM FAILURE___:
with 2nd line detail
DIAGNOSTIC ALARM:
with 2nd line detail
MAINTENANCE ALERT:
Replace Battery
