GEK-106310AE F650 Digital Bay Controller 3-45
3 HUMAN INTERFACES. SETTINGS & ACTUAL VALUES 3.2 HUMAN MACHINE INTERFACE (HMI)
3
3.2.6.2 TEXT MENU HIERARCHY
The structure of HMI text menu is similar to the EnerVista 650 Setup in the actual values and settings (view and change)
menus.
The main menu shows the following options:
Table 3.32: GENERAL OVERVIEW OF MAIN TEXT MENU:
NAME DESCRIPTION NAVIGATION IN MENU
Actual Values Actual values of all the signals available in device.
Status of protection and control elements,
measurements, inputs and outputs, etc.
Press shuttle key or enter key to enter next level.
Press ESC to return to default main screen.
Snapshot events Visualization of all snapshot events in text mode (two
screens for each snapshot event). In graphical displays
there can be seen in a dedicated screen.
Press shuttle key or enter key to visualize snapshot
events in text menu. Press ESC to return to default
main screen.
Fault Report Fault reports information available in HMI (two screens
for each fault report)
Press shuttle key or enter key to enter next level.
Move Up/Downto see all the available fault reports
in device. Press shuttle key or enter key to enter
particular information for fault report selected.
View Settings Visualization of all protection and control settings
available in device.
Press shuttle key or enter keyto enter next level.
Move Up/Down to select submenu. Press ESC to
return to previous level.
Change Settings Menu that allows changing all protection and control
settings available in device. Inputs and outputs settings,
relay configuration and logic configuration are not
available in HMI, only via EnerVista 650 Setup
software.
Press shuttle key or enter key to enter next level.
Move Up/Down to select submenu. Press esc to
return to previous level.
Date & Time Date and time visualization and modification by user. First mode is visualization. Press again shuttle key
or enter key to start modification in date and time.
Press ESC to return to previous level.
Commands Operations execution in local mode. Move Up/Down to pre select operation. Press
shuttle key or enter key to select and confirm. Press
ESC to return to previous level.
Password Password menu for settings and commands Move Up/Down to select submenu. Press shuttle
key or enter key to enter next level. Press ESC to
return to previous level.
Select Main Screen Selection of default main screen in text menu. Move Up/Down to select the default main screen
type. Pressshuttle key or enter key to confirm.
Select Language Language selection. Between default language (see
ordering code) and English.
Move Up/Down to select the default language.
Press shuttle key or enter key to confirm selection.
Switch the relay off and on.
< - return Return to previous level Press shuttle key or enter key to return to previous
level.
