2-30 F650 Digital Bay Controller GEK-113000AE
2.5 TECHNICAL SPECIFICATIONS 2 PRODUCT DESCRIPTION
2
2.5.9 CONTROL POWER SUPPLY
2.5.10 COMMUNICATIONS
LOW RANGE (LO) ALL RANGES
Nominal DC Voltage: 24 to 48 V Power consumption Typical =25 VA, Maximum =45 VA
Min/Max DC Voltage 19.2 / 57.6 V Display backlight auto power-off mode after 15 minutes without
touching any key, in order to ensure long life and minimum
consumption
Note: Low range is DC only
Voltage Loss hold-up time:
24Vdc 30 ms
48Vdc100ms
HIGH RANGE (HI) INTERNAL FUSE
Nominal DC Voltage: 110 to 250 V V 250VAC
Min/Max DC Voltage 88 / 300 V I 2,5A
Nominal AC Voltage: 120 to 230 V Size 5 x 20 mm
Min/Max AC Voltage 102 / 250 V Type Quick acting (F)
Voltage Loss hold-up time 200m typical, worst
case 100 ms without
unit reset
UL, listed miniature Fuse
FRONT PORT:
Front port: COM2
Type RS232/USB
Baud Rate 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600 y 115200 bauds
Default Baud Rate 19200
Protocols available:
ModBus
®
RTU / DNP 3.0
Typical distance: 3 m
Isolation: 2 kV
ASYNCHRONOUS REAR PORTS:
None or two rear ports (depending on model): COM1, COM2 (rear COM2 multiplexed with front port)
Type (depending on model):
Model F None
Model A Redundant RS485
Model X Redundant RS485 + fiber CAN for inputs/outputs module
Model P Redundant 1mm-plastic F.O.
Model Y Redundant 1mm-plastic F.O. + fiber CAN for inputs/outputs module
Model G Redundant multimode glass F.O.
Model Z Redundant multimode glass F.O. + fiber CAN for inputs/outputs module
Model C Cable CAN port for I/O module
Model M Cable CAN port for I/O module (cable) + RS485 (ModBus RTU)
Optic Features for ST connectors devices: Wave length: 1300nm
Fiber type: multimode 62.5/125 μm or 50/125 μm
Baud Rate: 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600 y 115200 bauds
Default Baud Rate 19200
