GE F650 - Summary of Firmware Upgrade Main Steps (*)

GEK-113000AE F650 Digital Bay Controller 5-29
5 BOOTCODE AND FIRMWARE UPGRADE 5.2 FIRMWARE UPGRADE VERSION V7.00 OR HIGHER
5
5.2.4 SUMMARY OF FIRMWARE UPGRADE MAIN STEPS (*)
1. INSTALL THE PROPER VERSION OF THE ENERVISTA 650 SETUP PROGRAM.
2. CONNECT ONE ETHERNET CABLE AT THE REAR ETHERNET PORT (CROSSOVER CABLE FOR BACK-
TOBACK CONNECTION AND STRAIGHT-THROUGH ETHERNET CABLE FOR HUB OR SWITCH).
3. SET THE APPROPRIATE IP ADDRESS IN THE RELAY.
4. SET THE APPROPRIATE IP ADDRESS IN THE PC.
5. FROM THE ENERVISTA 650 SETUP PROGRAM SELECT “Communications > Upgrade Relay”.
6. SELECT THE NECESSARY FILE (DCL000CAXXX.SDF) FOR DEVICE UPGRADING.
7. ENTER THE IP ADDRESS, PORT and UNIT IDENTIFIER OF THE RELAY.
8. PRESS UPGRADE FILE AND INITIATE THE UPGRADE PROCESS.
9. TO COMPLETE THE PROCEDURE, SWITCH OFF AND BACK ON THE RELAY WHEN REQUIRED BY THE
PROGRAM.
10. THE SETTINGS AND CONFIGURATION ARE NOW SET TO FACTORY DEFAULT.
11. SEND THE NEW SETTINGS AND CONFIGURATION FILES TO THE RELAY IF NECESSARY.
Note: Please see chapter 13 F650 TROUBLESHOOTING GUIDE if there is any problem during the upgrading
process.
