GEK-113000AE F650 Digital Bay Controller D-1
APPENDIX D D.1 FACTORY DEFAULT SETTINGS
D
APPENDIX D FACTORY DEFAULT CONFIGURATIOND.1 FACTORY DEFAULT SETTINGS
PRODUCT SETUP>COMMUNICATION SETTINGS >SERIAL PORTS
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
Baud rate for COM1 COM1 Baud Rate 19200 N/A [300 : 115200]
Baud rate for COM2 COM2 Baud Rate 19200 N/A [300 : 115200]
Parity for COM1 COM1 Parity NONE N/A [NONE:ODD:EVEN]
Parity for COM2 COM2 Parity NONE N/A [NONE:ODD:EVEN]
PRODUCT SETUP>COMMUNICATION SETTINGS >NETWORK (ETHERNET)
NETWORK (ETHERNET)1 > NETWORK (ETHERNET)2
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
1st octet of IP address IP Address Oct1 0 N/A [0 : 255]
2nd octet of IP address IP Address Oct2 0 N/A [0 : 255]
3rd octet of IP address IP Address Oct3 0 N/A [0 : 255]
4th octet of IP address IP Address Oct4 0 N/A [0 : 255]
1st octet of Netmask Netmask Oct1 0 N/A [0 : 255]
2nd octet of Netmask Netmask Oct2 0 N/A [0 : 255]
3rd octet of Netmask Netmask Oct3 0 N/A [0 : 255]
4th octet of Netmask Netmask Oct4 0 N/A [0 : 255]
1st octet of Gateway Gateway IP Oct1
0
N/A [0 : 255]
2nd octet of Gateway Gateway IP Oct2
0
N/A [0 : 255]
3rd octet of Gateway Gateway IP Oct3
0
N/A [0 : 255]
4th octet of Gateway Gateway IP Oct4
0
N/A [0 : 255]
**For firmware versions 7.00 or higher; the Network settings are the ethernet communication parameters are as follow
PRODUCT SETUP>COMMUNICATION SETTINGS >NETWORK (ETHERNET)
NETWORK (ETHERNET)1 > NETWORK (ETHERNET)
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
1st octet of IP address IP Address Oct1 0 N/A [0 : 255]
2nd octet of IP address IP Address Oct2 0 N/A [0 : 255]
3rd octet of IP address IP Address Oct3 0 N/A [0 : 255]
4th octet of IP address IP Address Oct4 0 N/A [0 : 255]
1st octet of Netmask Netmask Oct1 0 N/A [0 : 255]
2nd octet of Netmask Netmask Oct2 0 N/A [0 : 255]
3rd octet of Netmask Netmask Oct3 0 N/A [0 : 255]
4th octet of Netmask Netmask Oct4 0 N/A [0 : 255]
**For firmware versions 7.00 or higher; on the Network settings are also located the settings for Redundancy.
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
Function permission
REDUNDANCY
MODE
INDEPENDENT N/A [INDEPENDENT; LLA;
PRP; HSR; RSTP;
DAISY_CHAIN]
Stablish priority for Port A
LLA Priority DISABLED N/A [ENABLED; DISABLED]
