GEK-113000AE F650 Digital Bay Controller 2-3
2 PRODUCT DESCRIPTION 2.3 OTHER DEVICE FUNCTIONS
2
2.3OTHER DEVICE FUNCTIONS
*This functionality is available from firmware version 7.00
** Maximun number of events can vary depend on firmware version. See details in section 2.5.3.3
INPUTS/OUTPUTS METERING COMMUNICATIONS
9 Analog Inputs: 5 current inputs (3 for phases,
1 for ground, 1 for sensitive ground), 4 voltage
inputs (3 for phases, 1 for busbar or auxiliary
voltage)
Metering Current for phases, ground and
sensitive ground inputs
Front RS232 port, USB port in HMI
option E, Two rear RS485/fibre optic
ports, 10/100 TX and 100 FX Mbps
Ethernet port
Digital Programmable Contact Inputs (up to 64) Voltages phase to phase and phase to
ground
ModBus Communications RTU and
over TCP/IP
Digital Programmable Contact Outputs (up to
16)
Real, Reactive and Apparent Power and
Power Factor
DNP Multimaster (3.0 Level 2)
32 Latched Virtual Inputs
32 Self-Reset Virtual Inputs
Three Phase Energy IEC 870-5-104
Virtual Outputs (up to 512) Frequency ModBus User Map
Tripping and closing circuit supervision Sequence components of currents and
voltages
IEC 61850
Remote Inputs/Outputs (GSSE and GOOSE
messages)
Pulse Counters IEC 870-5-103 protocol
Analog Inputs (dCmA) Analog Comparators
*Digital Counters
USER INTERFACE RECORDS OTHERS
Alphanumerical display (4x20) Data Logger
Breaking Arcing Current (I
2
t)
Graphic display (16 x 40) Demand Breaker Control
User Programmable LEDs (15) Event Recorder (up to 128 configurable
events)
IRIG-B synchronization/SNTP/
IEEE 1588
User Programmable Keys (up to 5) Fault Locator and Fault report (up to 10
records)
Logic Equations (PLC Editor)
Easy menu management Oscillography (up to 20 records) Operations (up to 24)
Configurable One-Line Diagram (Graphic
model only)
Snapshot Events (up to 1023)** Web Server Application
Phasor Diagram (available in EnerVista 650
Setup)
